Commands

Integration with 3rd Party Applications SpectroRx (SPECTRUM Resolution Expert)

6-2 User’s Guide 5.0rev1

All SpectroRx commands are located in the CBR directory in the SPECTRUM

directory. The

cbr_get_case

and

cbr_retrieve

commands have a

nogui

option that enables you to receive information in a string format.

Commands

This section describes each SpectroRx command in detail.

cbr_allcases

Description: Displays a list of all the cases in the cbr library.

Syntax: cbr_allcases

Returns: A list of all the cases in the cbr library. You can select cases from

the list and open them, one at a time, by clicking on the Open Case

button.

Example: cbr_allcases [Return]

NOTE

Before you use SpectroRx commands, make sure the ND_PATH variable is set

to the ndlib directory in the SPECTRUM directory. For example, if you are

running the C shell, type the following on the command line:

setenv ND_PATH /<SPECTRUM>/ndlib

Alarm

Case

SpectroRx

Open Case

9 Cases

Case 1

too much trafÞc on link

Check trafÞc on other links and re-distribute nodes

accordingly

Case 2

device not pingable

Agent is down.

Case 3

server unreachable

Server ÒbubbleÓ is not working. Clients are not able to

access

Case 4

connection lost

Replace bent pin.

Case 5

router overstressed

Wait 30 minutes.

Case 3

server unreachable

Server ÒbubbleÓ is not working. Clients are not acces

1 2 ... 79 80 81 82 83 84 85 86 87 88 89 ... 125 126
